Key data at a glance

The replacement / spare jaws in jaw width 46 mm fit the two 5-Axis Vises Makro•Grip® 46 (item number 48065-46) and Makro•Grip® 46 micro (item number 48040-46). With their holding serration on both sides, unmachined parts can be securely clamped at just 3 mm clamping depth with the best accessibility.

Dimensions

Jaw width: 46 mm (1.81")

Workpiece shape

cubic

Packaging Unit

1 Pair

Weight

0.28 kg (0.62 lbs)

Material

Steel

Makro•Grip® Stamping Technology and Raw Part Clamping

The Makro•Grip® 5-Axis Vise and its unique benefits of the stamping technology has been considered „The Original“ and a benchmark in the 5-face machining of raw parts for years. Its compact design and high holding forces make the Makro•Grip® 5-Axis Vise the ideal clamping device for machining raw parts.

Holding force Thanks to the form-fit clamping principle, highest holding forces can be achieved with Makro•Grip®, even at low clamping pressure.
Process reliability Clamping with Makro•Grip® provides maximum process reliability and is easy on the workpiece to be processes at the same time.
Accessibility The compact Makro•Grip® self-centering vises guarantee ideal accessibility in the 5-axis machining of raw parts.
