Key data at a glance
With this 2-fold plate with the grid size 52 mm, two clamping positions are actuated with on screw. The multiple plate is suitable for the 3- and the 4-sided clamping tower, as well as the Quick•Tower clamping tower for horizontal machining centers. It can also be mounted as a multiple clamping solution on the customer’s own fixtures and towers.
Dimensions
208 x 104 x 27 mm (8.19" x 4.09" x 1.06")
Cross-plate grid possible
Ja
Clamping type
Multi clamping
Clamping units
2-fold
Mounting bores
for 186 x 82 mm hole spacing
Keyways
No, but not necessary
M5 indexing bores
No, but possible (service)
Packaging Unit
1 Piece
Weight
3.8 kg (8.38 lbs)
Material
Steel
More features:
供货范围：
1 x Zero-Point plate
4 x Quick•Point® plastic covers ø 20 mm (item number 45008-20)
4 x Socket head screw M10 x 35
