Key data at a glance
The new Makro•Grip® 46 is the successor version of the popular, small 5-axis vise from LANG Technik (item no. 47065). With its compact base body, it is ideally suited for workpiece clamping of small components, for example from medical technology. The 5-Axis Vise proves to be extremely practical due to its small footprint of just 77 x 77 mm. Even with the smallest zero point plates, this vise does not protrude, which makes it particularly predestined for multiple part clamping.
Clamping range
0 - 65 mm (0" - 2.56")
Dimensions
77 x 77 x 65 mm (3.03" x 3.03" x 2.56")
Clamping method
by form-fit / by friction
Workpiece shape
cubic
Packaging Unit
1 Piece
Weight
1.75 kg (3.86 lbs)
Material
Steel
More features:
Single components features:
Clamping Studs
Diameter
16 mm (0.63")
For grid size
52
Threaded pin
M8
Spare Jaws
Dimensions
Jaw width: 46 mm (1.81")
Spindle + Center Piece
Spindle length
82 mm (3.23")
Thread pitch
M12 x 1
